S3AS is the 3-axis manual tool change CNC router, designed for optimal material stability and superior cut quality, featuring AC servo motors for chatter-free, bright finishes. The machine combines vacuum adsorption with a pressure roller for secure material holding, while industrial controls and specialized positioning devices ensure high accuracy in a cost-effective package.
Adopt industrial seamless welded structures design, identify the deformation of welded structures by finite element analysis, also use low temperature annealing control, in order to ensure the best strength and rigidity.
X.Y axis adopt imported high-precision helical rack-and-pinion transmission systems, Z axis adopts a high-precision TBI ball screw drive, ensuring smooth movement, excellent positioning accuracy and consistent machining repeatability.
Equipped with 6 sets of adjustable support feet, the machine allows precise height leveling and stable placement on various ground conditions. This design effectively maintains horizontal balance, reduces vibration during operation, and ensures stable and high-precision machining performance.
The integrated cabinet plus rocker tool box improves on-site neatness, and enables orderly storage and quick access to engraving tools, enhancing overall work efficiency.
Supports a wide range of professional engraving and design software, including Type3, Casmate, Artcam, Wentai, JD Paint and other mainstream CAM/design programs, ensuring strong adaptability, flexible operation and convenient data import for diverse processing requirements.
| Parameters |
Specification |
| Working Area (XY) |
1300x2500mm(4x8ft) |
| Z axis travel(mm) |
200 |
| Positioning Accuracy |
±0.05/300mm |
| Repositioning Accuracy |
±0.05 |
| Lathe Structure |
Annealing heavy-duty structure |
| Guide |
Original Germany ROUST |
| Z Structure |
Original TAIWAN TBI Ball Screw transmission |
| Woking table |
5 zones vacuum plus aluminum T-slot table |
| Vacuum pump |
7.5KW air vacuum pump |
| Max. Rapid Travel Rate |
35000mm/min |
| Max. Working Speed |
20000mm/min |
| Spindle Power |
5.5KW water cooling ATC Spindle |
| Spindle Speed |
24000rpm/min |
| Spindle cooling |
Industry water chiller |
| Cutting bits cooling |
ATC spray cutting fluid |
| Drive Mode |
Leadshine AC servo motors and drivers |
| Reducer |
High precision planetary reducer |
| Lubrication system |
Automatic lubrication system |
| Dust cleaning system |
Dust collector,spindle cover, pipe and bracket |
| Operating System |
CNCSUPER 3 axis controller |
| Diameter of cutter |
3.175-12.7mm |
| Collet |
ER25 |
| Tool setting |
ATC tool sensor |
| Software compatibility |
Artcam, Type3 |
| Command language |
G Code & uoo & mmg & plt |
| Working voltage |
380V/50HZ/3PH (Can be customized) |
| Weight |
1500KG |
Wood/Furniture: Wave Plate, MDF, fine pattern, antique furniture, wooden door, Screen, craft sash, composite gates, cupboard doors, interior doors, headboards and so on.
Advertising: advertising identification, sign making, acrylic engraving and cutting, crystal word making,showcase, display, and other advertising materials derivatives making.
Industry: A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, granite, plastic sheeting, PCB, PVC wooden planks and other non-metallic mold.
Artwork and Decoration: Wood crafts, gift box, jewelry box.
Others: Relief sculpture and 3D engraving.
MATERIAL
Soft Metals: Aluminum, copper, brass, and titanium.
Wood & Wood Composites: Solid hardwoods/softwoods, MDF, plywood, and melamine-faced chipboard.
Industrial Plastics: Acrylic, PVC, Polycarbonate, ABS, and Teflon.
Advanced Composites: Carbon fiber, fiberglass, epoxy resin, and insulation boards.
Other Materials: Artificial marble, foam (polyurethane/EPS), and rubber.
